20T Lab Manual Cold Isostatic Press Hydraulic CIP Pressing Machine

Sales Manager: Gia

Email: Gia@tmaxlaboratory.com

Wechat: Dingqiuna

Item No.:
TMAX-CIP-20J
Payment:
L/C, T/T, Western Union, Credit Cards, Paypal
Shipping port:
Xiamen Port
Lead Time:
15 Days
Certificate:
CE, IOS, ROHS, SGS, UL Certificate
Warranty:
One year limited warranty with lifetime technical support

Product Details

20T Lab Manual Cold Isostatic Press Hydraulic CIP Pressing Machine

TMAX-CIP-20J is a CE Certified and the smallest cold isostatic pressing (CIP) machine used for laboratory powder pressing. It has a 30mm ID hydraulic chamber made by ultra strength stainless steel, which can provide isostatic pressure up to 300 Mpa via a 20T manual hydraulic press. It is an excellent tool to prepare high-density compound pellet and small diameter rod. CIP-20J has the small footprint and can be placed in glove-box to prepare air-sensitive materials. A plastic protection cover is included.

Main Features

a).Small size, light weight,No oil, easy to carry.

b).High speed steel imported from Japan

c).Digital display pressure gauge 0.1MPa,Pressure control is more accurate.

d).The oil pool is easy to replace oil on the main surface of the host, and the hydraulic oil filter is added to the oil path.

e).Special plunger, special custom sealed structure, good sealing effect, no oil leakage

f).The upper plate adopts six angle screws in electroplating sunk head. It is beautiful and saves space.

g).One one main plate structure, oil pool, main board, oil cylinder, on one body, no seal connection.

h).Lengthening spring, the rebound effect is good, not easy to deform, can realize the oil cylinder 30mm return no deformation.

i).The Aluminum Alloy handwheel, beautiful, practical, durable, not easy to damage

Specification

20T cold isostatic Pressing machine
Application	Laboratory CIP Pressing
Hydraulic pressing range	0~20T(0-21MPa)
Piston Diameter	O.D110mm
Structure	oil tank,machine base No sealing connection, no oil leak point
Pressure gauge	Digital pressure gauge
Maximum piston distance	40mm
Environment temperature	10~40 degree
CIP Pressure range	0~300MPa
CIP Tank dimension	O.D30*120mm
Outer dimension	305195600mm
Gross Weight	105Kg

Pressure conversion

Real Pressure	System Pressure	Tank inner pressure
1.7T	1.86MPa	25MPa
3.5T	3.72MPa	50MPa
5T	5.57MPa	75MPa
7T	7.43MPa	100MPa
8.7T	9.29MPa	125MPa
10.5T	11.2MPa	150MPa
14T	14.8MPa	200MPa
17.5T	18.6MPa	250MPa
21T	22.3MPa	300MPa
