Item No.:
TMAX-PC-600C/CGPayment:
L/C, T/T, Western Union, Credit Cards, PaypalShipping port:
Xiamen PortLead Time:
15 DaysCertificate:
CE, IOS, ROHS, SGS, UL CertificateWarranty:
One year limited warranty with lifetime technical support5T 500C Double Heat Plate Manual Hot Press with Imported Heat Insulation Board
Technical Parameters
|
Instrument model |
PC-600C/CG(500℃) |
|
Pressure range |
0-5.0 tons |
|
Piston diameter |
Chrome plated cylinder φ50mm (d) |
|
Overall structure of main body |
Equipment without sealing connection to reduce oil leakage point |
|
Mold heating temperature |
Room temperature -300.0℃/500.0℃ |
|
Constant temperature time |
1sec~∞sec |
|
Temperature control precision |
0.1℃ |
|
Insulation method |
Imported heat insulation board |
|
Cooling method |
Water-cooled rapid cooling [water cooler optional] |
|
Mould size |
Double plate heating 120*120mm(M*N) |
|
Working space |
140*140*60mm |
|
Size of the whole machine |
250*230*390mm (L*W*H) |
|
Power supply |
700W(220V/110V can be customized) |
|
Main machine weight |
55Kg |
|
Dimensions of powder tablet press |
|
1 Standard exported package: Internal anticollision protection, external export wooden box packaging.
2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.
3 Responsible for the damage during the shipping process, will change the damage part for you for free.
