Continuous Roll to Roll Coater Planar And Fiber Deposition

Model: KT-DM30

Equipment Introduction:

This equipment can not only complete planar coating but also continuous fiber coating processes. On both sides of the cavity, there are retractable and expandable chambers, which enable continuous rotational evaporation coating on the surface of fiber-like materials. This equipment is applied for vacuum evaporation coating of optical films, organic films and metal films, etc. It is particularly suitable for high-tech enterprises, research institutions and universities for membrane layer research and the development of membrane systems.

Detailed technical parameters:

Cavity dimensions: Diameter approximately 280mm, height approximately 450mm (subject to actual design)

Limiting vacuum degree: 6.7*10-5 pa

Evaporation source: 2 sets of evaporation sources, with water cooling

Evaporation power supply: 2000W, dual-output one-to-two

Film thickness meter: Domestic film thickness meter, resolution: 0.1 Å

Vacuum pumping system: Molecular pump (300L/S) + Mechanical pump (4L/S)

Flat sample stage: Adjustable height (250~350mm), adjustable rotational speed (0~30 revolutions per minute)

 Control system: Touchscreen automatic control

Roller sample stage: Rotation: Self-rotation (1~30 revolutions per minute), horizontal linear speed

1~100mm per minute, evaporation height 250mm
