Item No.:
TMAX-HGPayment:
L/C, T/T, Western Union, Credit Cards, PaypalShipping port:
Xiamen PortLead Time:
20 DaysCertificate:
CE, IOS, ROHS, SGS, UL CertificateWarranty:
Two years limited warranty with lifetime technical support
|
Model number |
HG-30F |
HG-30DF |
HG-60DLF |
HG-30LF |
|
Item number |
1012007001 |
1012009001 |
10120010001 |
1012008001 |
|
Pumping speed (L/min) |
30 |
30 |
60 |
30 |
|
Ultimate pressure (Mpa) |
>0.0.8(200mbar) |
>0.095(50mbar) |
>0.0.8(200mbar) |
>0.0.8(200mbar) |
|
Positive pressure (psi) |
0 |
0 |
40 |
40 |
|
Series of series |
1 |
2 |
2 |
1 |
|
Motor power (w) |
180 |
180 |
180 |
180 |
|
Dimensions (mm) |
250*135*210 |
315*135*210 |
315*135*210 |
250*135*210 |
|
Weight (kg) |
7.5 |
10 |
10 |
8 |
|
Material diaphragm |
PTFE anti-corrosion rubber |
PTFE anti-corrosion rubber |
PTFE anti-corrosion rubber |
PTFE anti-corrosion rubber |
|
Noise (db) |
< 50 |
<50 |
<50 |
<50 |
|
Function |
Negative pressure |
Negative pressure |
Positive and negative pressure (positive pressure is optional) |
Positive and negative pressure |
|
Type |
Protection against corrosion |
Protection against corrosion |
Protection against corrosion |
Protection against corrosion |
1 Standard exported package: Internal anticollision protection, external export wooden box packaging.
2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.
3 Responsible for the damage during the shipping process, will change the damage part for you for free.
