Lab High Precision Ultraviolet Germicidal Anaerobic Incubator with Display Screen

Display screen

A. Scope of application

Anaerobic incubator is a special device for bacterial culture and operation in an anaerobic environment. It can provide strict anaerobic state, constant temperature culture conditions and a systematic and scientific working area. In this device, anaerobic organisms that are difficult to grow can be cultivated, and the risk of death caused by contact with oxygen during operation in the atmosphere can be avoided in the past. Therefore, this device is an ideal equipment for anaerobic biological detection and scientific research.

B. Structural characteristics

a. The anaerobic incubator is composed of constant temperature culture room, anaerobic operation room, sampling room, gas path and circuit control system, box frame and other parts. The machine has the characteristics of good anaerobic environment, good sealing performance, high temperature control accuracy, good stability, easy to use, good economy and reliability

b. The use of scientific means to achieve the anaerobic environment of high precision, good constant performance, constant temperature anaerobic environment, easy for the operator to operate in the anaerobic environment and anaerobic bacteria culture.

c. The anaerobic incubator is a new generation of large screen true color touch screen microcomputer control type newly developed by our company, which can accurately and intuitively control the temperature and gas of the incubator, safe and reliable. It has the characteristics of simple, intuitive and convenient operation.

d. The system adopts PLC core controller, supplemented by high precision temperature sensor, oxygen sensor, temperature control module, analog module, high control precision, good stability, high safety; Humanized human-machine interface, convenient for operators to monitor process data in real time.

e. With imported oxygen sensor, you can observe the oxygen concentration status in the operating room at any time (oxygen concentration can be selected to switch % or PPM function).

f. Deaerator is available in the operation room.

g. With USB interface, the memory can store 6 months of data.

h. The box is equipped with ultraviolet germicidal lamp, and the gas is filtered into the box, which can effectively avoid bacterial contamination.

i. The gas path device uses a light touch switch to control the solenoid valve, which can adjust the flow rate accurately and input various required gases arbitrarily.

j. The double door widening design of the incubator changes the phenomenon that when a single door is opened, it will touch the front window of the operation room, and the widening can place more petri dishes.

k. The culture room and operation room are made of stainless steel plate, smooth and elegant, anticorrosive and durable.

l. The front window of the operation room is made of thick transparent impact-resistant special glass plate, and the operation uses special gloves, which is reliable, comfortable, flexible and easy to use.

m. Fitted with leakage protector.

C. Technical parameter

1 Standard exported package: Internal anticollision protection, external export wooden box packaging.

2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.

3 Responsible for the damage during the shipping process, will change the damage part for you for free.
